Tonheflow motorized valve manufacturer
Tonhe mainly produces motorized shut off ball valve from 1/4" to 2",
Some valves approved NSF61-G, CE, ROHS and other international certification.
Tonheflow A150-T-0-B CR301 DC12V actuator 12 foot 3 wires balck cable Sleeve 9 9.7
Min.Order Quantity: 1 Piece/Pieces
Supply Ability: 5000 Piece/Pieces per Month
Port: ningbo,Shanghai
Payment : T/T, Paypal
Service On Line
Supply Ability: 5000 Piece/Pieces per Month
Port: ningbo,Shanghai
Payment : T/T, Paypal
Service On Line
Tonhe is a china manufacturer, we focus on mini motorized valve(1/4" - 2"), which are CE, RoHS, IP67 approved, and SS valve and PVC valve body NSF61 approved. Our company also SGS ISO9001 approved.
Technical Parameters:
| Suit for Valve size |
NPT this actuator can suit for 1/2"-2" valve |
| Maximum working pressure | 1.5 MPa |
| Circulation medium | Fluid, air |
| Rated voltage | DC12v |
| Wiring control methods | CR301 |
| Working current | ≤1.5A |
| Open/close time |
≤8S |
| Life time | 70000 times |
| Valve Body material |
Stainless Steel |
| Actuator material | Engineering Plastics |
| Sealing material | EPDM & PTFE |
| Actuator rotation | 90° |
| Max. torque force | 15Nm |
| Cable Length |
0.5m,1.5m（Optional） |
| Environment temperature | -15℃～50℃ |
| Manual override | Yes |
| Indicator | Yes |
| Protection class | IP67 |
Tonhe A150 valve actuator feature
torque:10-20NM, valve actuator color can be gray or blue or black color or white,we are the manufacture, so we also can custom-made terminal connector and logo for you, actuator with manual override, can be turn left or turn right 360 degree.
Assemble drawing
A150 actuator drawingWiring diagram
CR301 Wiring Diagram ( 3 wires control )
·RD & GR connect with positive, BK connect with negative
·When OPEN( RD) & SW connected , the valve open, the actuator automatically power off after in place , valve remains fully open position
·When CLOSE(GR) & SW connected, the valve closed, the actuator automatically power off after in place, valve remains fully closed position.
﹡Suitable Working Voltage: DC12V, DC24V,AC24v,DC12v-24v
﹡Exceeding the working voltage is forbidden
Our electronic components are basically imported, all choose the better quality of the accessories, such as switches, we use better quality Taiwan switch.
Our electronic components are basically imported, all choose the better quality of the accessories, such as switches, we use better quality Taiwan switch.
When you inquiry the valve, pls confirm the detail technical data :
1)valve size2)material, brass or stainless steel or PVC?
3)working voltage
4)wiring diagram
5)thread BSP or NPT?
6)quantity?
7)cable length, 0.5m is OK for you?
